HS7364 ToolkitRC M9 600W 20A USB Fast Charing DC Smart Charger Adjustable Screen Angle with Audio Function For 1-8S Lipo LiFe Battery

M9 SPEC

Measurer

PWM：880-2200us @ 20-400Hz

PPM：880-2200us * 8CH @ 20-50Hz

SBUS：880-2200us * 16CH @ 20-100Hz

voltage：1.0-5.0V @ 1-8S

Internal resistance：0.1 mR-99R @ 1-8S

ESC：600W @ 20A

Charger

input voltage：7.0-35.0V @MAX 25A

battery type：Lipo LiHV LiFe Lion LTO@1-8S NiMh @1-20S Pb @1-10S

balance current：1000mA @ 4.2V

charging power：600W @MAX 20A

discharge power：600W @MAX 20A Recycle mode 20W@3A Normal mode

USB：65W@5.0-20.0V or Upgrade by USB-A

Output

PWM:500-2500us @ 20-1000Hz

PPM:880-2200us * 8CH @ 20-50Hz

SBUS:880-2200us * 16CH @ 20-100Hz

power supply:1.0-35.0V @1.0-20A mode:CC CV

Overcurrent response:<5ms

General

Product size：108*71*36mm

product weight：235g

packing size：135*81*44mm

packaging weight：330g

LCD：IPS 2.4 inch LCD 320*240
